Available Models
6600
Tri-fold Toolbar up to 62' wide
The 6600 is the ultimate upgrade for high efficiency placement and maximum productivity
Heavy duty 7" x 7" x 1/2" wall thickness Double Toolbar Center Section
Covers up to 24 (30") rows
Comes with either hydraulic pump system with an automatic rate controller or manual set ground drive pump
6500 Series
Double bar front-mounted toolbar with hydraulic parallel lift
Extra heavy duty caddie
Designed for liquid strip till or hi-pressure 28%
6400 Series
Optimized productivity with superior visibility and control
Enhanced nutrient application with controlled precision placement that is proven reliable for today's tough applicating environments
Single bar heavy duty front-mounted toolbar
Great row visibility
Accurate applicator control
6300 Series
Rugged manufacturing and quality performance
Durable construction combined with advanced toolbar designs to deliver effective and efficient application across a wide range of field conditions
Heavy duty front-mounted toolbar
Great row visibility
Accurate applicator control
6600 Specifications
- Heavy-duty 7" x 7" x 1/2" wall thickness double toolbar section
- Primary Wings, Secondary Outer Wings are Single Bar
- Toolbar Lengths up to 62'
- 14' 5" Center Section
- All Hydraulic Fold Toolbar
- 1,700 Gallon Elliptical Tank
- 17'-2" Length
- 18' Travel Width
- 13' 4" Height
- 34 1/2" Ground Clearance of Frame
- 120" to 144" Adjustable Wheel Track with Optional 144" to 160"
- 45 x W12-10 bolt Rims to 46 x 12, 10 bolt Rims
- Heavy Duty 10 on 10" Hubs
- Single or Dual Piston Pump or Hydraulic Driven Pump with Control Systems Available
- Heavy Duty Pole Jack
- Adjustable CATIV/V Tractor Clevis
- AG37 Generation III Coulters with 20" Blades
- Stainless Steel Manifolds & Hose
- Check Valves on Each Row
6500 Specifications
- Heavy-duty 4" x 6" x 1/2" wall thickness double toolbar section
- Primary Wings, Secondary Outer Wings are Single Bar
- Toolbar Lengths up to 42'
- 13' 6" Center Section
- Toolbar Lengths Up To 42'
- 1,300 Gallon Elliptical Tank
- 15'-3" Overall Length
- 18' 8" Travel Width
- 12' 6" Height
- 34 1/2" Ground Clearance of Frame
- 120" to 144" Adjustable Wheel Track
- 45 x W12-10 bolt Rims to 46 x 12, 10 bolt Rims
- Heavy Duty 10 on 10" Hubs
- Single or Dual Piston Pump or Hydraulic Driven Pump with Control Systems Available
- Heavy Duty 4" x4" Pole Jack that Swivels Out of the Way
- Adjustable CATIII/IV Tractor Clevis
- Heavy Duty Coulter Assemblies
- 7-pin Flashing/Warning Light Kit
6400 Specifications
- 7" x 7" x 1/2" wall
- Single Bar Center Section
- 3/8" Wall Wings27.5', 32.5'. 37.5' and 42.5' Available Toolbar Widths
- 13' 6" Center Section
- Toolbar Lengths Up To 42.5'
- 1,400 or 1,700 Gallon Elliptical Tanks Available
- Hitch to Rear Plumbing
- 19' 3" Length with Plumbing
- 17' 8" Travel Width with Coulters on 30" Rows
- 12' 7" Height
- 34" Ground Clearance of Frame
- 120" to 144" Adjustable Wheel Track
- 45 x W12-10 bolt Rims to 46 x 12, 10 bolt Rims
- Heavy Duty 8 on 8" Hubs
- Single or Dual Piston Pump or Hydraulic Driven Pump with Control Systems Available
- Heavy Duty 4" x4" Pole Jack
- Adjustable CATIII/IV Tractor Clevis
- 7-pin Flashing/Warning Light Kit
6200 Specifications
- Double Bar Center Section of 4" x 6" Heavy Wall Tubing
- 26' 30' 35' Lengths
- 11' Center Section
- Toolbar Lengths Up To 35'
- Hydraulic Folding Wings and Hydraulic Lift
- 715 or 1,000 Gallon Fully Drainable Leg Tank
- 10' 6" Length with Plumbing
- 15' 6" Travel Width with Coulters on 30" Rows
- 13' 7" Height
- 32 1/2" Ground Clearance of Frame
- 74" to 120" Adjustable Wheel Track
- 16.5 x 16.1 Implement Tires or 385.65RR-22.5 Tires (Required for 1,000 Gallon Tank)
- Heavy Duty 8 on 8" Hubs
- Single or Dual Piston Pump or Hydraulic Driven Pump with Control Systems Available
- Heavy Duty 4" x4" Pole Jack that Swivels Out of the Way
- AG 37 Coulter
