Available Models
MT16
514 cu. ft. Tender
4 Compartments
MT24
771 cu. ft. Tender
6 Compartments
MT32
1,028 cu. ft. Tender
8 Compartments
MT16 Specifications
- 514 cu. ft. - 14.55 cu. meters
- 4 Separate 409 SS Hoppers with 4 Individual Control Gates
- 3,435 lbs Tare Weight (1,556 kg)
- 160" Minimum Auger Height Discharge Reach 160"
- 133" Max Auger Height Discharge Reach
- 142" Discharge Height (361" Raised) From Frame Base - 16 ft Auger
- 34" x 196" Base Dimensions (86 x 492 cm)
- 81" Body Height (206 cm)
- 10" Discharge Auger Size (25cm)
- 8" Horizontal Auger Size (20 cm)
- 95 cu. ft. Bolt on Extensions
MT24 Specifications
- 771 cu. ft. - 21.8 cu. meters
- 6 Separate 409 SS Hoppers with 6 Individual Control Gates
- 4,500 lbs Tare Weight (2,041 kg)
- 160" Minimum Auger Height Discharge Reach
- 133" Max Auger Height Discharge Reach
- 142" Discharge Height (361" Raised) From Frame Base - 16 ft Auger
- 34" x 292" Base Dimensions (86 x 742 cm)
- 81" Body Height (206 cm)
- 10" Discharge Auger Size (25cm)
- 8" Horizontal Auger Size (20 cm)
- 142 cu. ft. Bolt on Extensions
MT32 Specifications
- 1,028 cu. ft. - 29.1 cu. meters
- 8 Separate 409 SS Hoppers with 8 Individual Control Gates
- 6,780 lbs Tare Weight (3,116 kg)
- 160" Minimum Auger Height Discharge Reach
- 133" Max Auger Height Discharge Reach
- 142" Discharge Height (361" Raised) From Frame Base - 16 ft Auger
- 34" x 396" Base Dimensions (86 x 1,005 cm)
- 81" Body Height (206 cm)
- 10" Discharge Auger Size (25cm)
- 8" Horizontal Auger Size (20 cm)
- 190 cu. ft. Bolt on Extensions
